Description
The Pall UE310AP20Z hydraulic filter element is designed for high-efficiency contamination control in hydraulic and lubrication systems. This replacement element uses high-quality glass-fiber media to capture fine particulate contamination while maintaining consistent fluid cleanliness throughout the filter's service life.
The UE310AP20Z replaces Pall's 5-micron Athalon element and provides a Beta 2000 filtration efficiency rating. Its stress-resistant media construction helps maintain stable filtration performance during changing flow rates, pressure fluctuations, cold starts, and increasing contaminant loading.
A laid-over pleat configuration increases the amount of usable filter media within the element while promoting uniform fluid flow and dirt loading. The coreless, cageless construction reduces element weight and disposal volume, while the fluorocarbon seal provides compatibility with a wide range of hydraulic and lubricating oils.
Specifications
| Filter Element Type | Hydraulic / Lubrication |
| Outer Diameter | 3.12" |
| Inner Diameter | 1.65" |
| Height | 20.59" |
| Filter Media | Glass Fiber |
| Micron Rating | 5 Micron |
| Filtration Efficiency | Beta 2000 |
| Flow Direction | Inside-Out |
| Seal Material | Viton / Fluorocarbon |
| Center Tube | Coreless |
| Collapse Pressure | 150 PSI |
| Replaces | Pall UE310AP20Z |
All manufacturers' names and part numbers are used for reference purposes only. This is a compatible replacement filter element and is not manufactured or endorsed by Pall Corporation.
Warranty Information
We guarantee our PALL UE310AP20Z filter replacement will meet or exceed the specifications, performance, and warranty of the Pall OEM hydraulic filter cartridge.
