Description
A direct aftermarket cross reference for the Hy-Pro HP16DHL8-6MV, this 6 micron microglass element is engineered to drop in without modification. The pleated synthetic microglass media captures 99.9% of contaminants at the rated size (Beta 1000).
The HP16DHL8-6MV element is 2.72" OD, 1.35" ID, 6.85" tall, with a single open end. It carries a Viton seal rated for 400°F max. It is made in an ISO 9001 certified facility. American-made.
Extra Information
Filter Media:
Microglass
Micron Rating:
5 Micron
Outside Diameter:
2.72"
Inside Diameter:
1.34"
Overall Height:
6.81"
End Configuration:
Single Open End
Gasket Material:
Viton (FKM)
Operating Temperature:
-13°F to 248°F
Replaces:
HYPRO HP16DHL8-6MV
Maximum Pressure Differential:
3,045 PSI
Warranty Information
We guarantee this aftermarket replacement for the HYPRO HP16DHL8-6MV hydraulic filter meets or exceeds the specifications and performance of the original element, backed by our satisfaction guarantee. Brand names are trademarks of their respective owners.
